10 mm Brushed DC Gear Motor
Model: MD010010
Parameters： Gearbox Stages 1 2 3 4 5 MAX. Continuous output torque (Nm) 0.01 0.03 0.1 0.15 0.15 MAX. Instant mobilization torque (Nm) 0.02 0.05 0.15 0.2 0.2 Reduction ratio 4 16 64 256 1024 Outer diam
- Diameter
- 10 mm
- Voltage Range
- 3.0 V
- Reduction Ratio
- 3-809
- Max. Transmittable Power
- 0.2 W
- Max. Continuous Torque
- 1,000 gf.cm
- Max. Continuous Input Speed
- 12,000 rpm
- Rated Speed Range
- 17-3917 rpm
- Operating Temperature
- -20…+85℃
Gearbox Specifications:
| Bearing | Porous bearing | Rolling bearing |
|---|---|---|
| Axial Endplay | ≤ 0.3 mm | ≤ 0.2 mm |
| Radial Loading on Output Shaft | ≤ 2 N | ≤ 7 N |
| Operating Temperature | -20℃ ~ +85℃ | |
Parameters：
| Gearbox Stages | 1 | 2 | 3 | 4 |
|---|---|---|---|---|
| Reduction Ratio | 3/5 | 13/19/28 | 46/69/102/151 | 168/249/368/546/809 |
| Max Rated Torque Of Gearbox (gf.cm max) | 1,000 | 1,000 | 1,000 | 1,000 |
| Max Instant Torque Of Gearbox (gf.cm max) | 2,000 | 2,000 | 2,000 | 2,000 |
| Gearbox Efficiency (%) | 87 | 74 | 63 | 56 |
| Length (mm) | 9.7 | 12.8 | 15.9 | 19 |
| Gear backlash | ≤ 3° | |||
Drawing:
Motor Specifications:
| Motors (Optional) | Brushed DC Motor |
|---|---|
| Voltage (Optional) | 3-12 V |
| Input Speed | ≤ 30,000 rpm |
| Current | 150 mA max |
Performance Data:
| Model | Rated Voltage (VDC) |
Rated Speed (rpm) |
Max Speed (rpm) |
Max. Rated Torque Of Gearbox (gf.cm) | Max Instant Torque Of Gearbox (gf.cm) |
Gear Ratio | Length (L1) (mm) |
Overall Length (L) (mm) |
|---|---|---|---|---|---|---|---|---|
| MD010010-3 | 3.0 | 3917 | 7500 | 1000 | 6000 | 3 | 9.7 | 24.7 |
| MD010010-5 | 3.0 | 2645 | 5000 | 1000 | 6000 | 5 | ||
| MD010010-13 | 3.0 | 1085 | 2308 | 1000 | 6000 | 13 | 12.8 | 27.8 |
| MD010010-19 | 3.0 | 742 | 1579 | 1000 | 6000 | 19 | ||
| MD010010-28 | 3.0 | 504 | 1071 | 1000 | 2000 | 28 | ||
| MD010010-46 | 3.0 | 307 | 652 | 1000 | 2000 | 46 | 15.9 | 30.9 |
| MD010010-69 | 3.0 | 204 | 435 | 1000 | 2000 | 69 | ||
| MD010010-102 | 3.0 | 138 | 294 | 1000 | 2000 | 102 | ||
| MD010010-151 | 3.0 | 93 | 199 | 1000 | 2000 | 151 | ||
| MD010010-168 | 3.0 | 84 | 179 | 1000 | 2000 | 168 | 19 | 34 |
| MD010010-249 | 3.0 | 57 | 120 | 1000 | 2000 | 249 | ||
| MD010010-368 | 3.0 | 38 | 82 | 1000 | 2000 | 368 | ||
| MD010010-546 | 3.0 | 26 | 55 | 1000 | 2000 | 546 | ||
| MD010010-809 | 3.0 | 17 | 37 | 1000 | 2000 | 809 |
* The above specifications are subject to change without prior notice. They are for reference only and can be customized as required.
