Slotless Brushless DC Motors

High Performance

Elevate magnet steel design with high-performance sintered NdFeB, emphasizing iron coercivity. Decrease outer diameter, reducing rotational inertia and enhancing air cooling through increased electromagnetic air gap.
Revolutionize stator cores for optimal performance: boost volume, secure a vacuum-tight surface, and directly bond wires to enhance heat dissipation and insulation reliability.

Note: The single motor is not sold separately, and needs to be sold as a whole with the gearbox

ironless or iron core winding.

ZHAOWEI BLDC motors: Key information at a glance.

Customize the configuration for your application as required. Please contact us for more solutions, this will be the right choice for you

	Diameter	Rated Voltage	Speed Constant	Stall torque(mNm)	Stall Current	Max. efficiency (%)
4 mm Brushless Coreless Motor MC0408-01	4 mm	5 V	16667 rpm/V	0.07 mNm	0.095 A	20
6 mm Brushless Coreless Motor CL0623-01	6 mm	3.5 V	5523 rpm/V	1.5 mNm	0.85 A	63
8 mm Brushless Coreless Motor MC0824-01	8 mm	12 V	3155 rpm/V	3.5 mNm	1.65 A	67
10 mm Brushless Coreless Motor MC1028-01	10 mm	12 V	2875 rpm/V	8.8 mNm	2.8 A	61
12 mm Brushless Coreless Motor MC1226-01	12 mm	12 V	2383 rpm/V	8.9 mNm	2.38 A	67
16 mm Brushless Coreless Motor MC1625-08	16 mm	12 V	1563 rpm/V	21.2 mNm	3.17 A	63.4
19 mm Brushless Coreless Motor MC1958-01	19 mm	36 V	1515 rpm/V	447 mNm	71.6 A	86
22 mm Brushless Coreless Motor MC2250-01	22 mm	24 V	669 rpm/V	627 mNm	3.7 A	86

* above specifications are for reference only.the specific parameters can be customized according to the customer's requirements.

Our Product Portfolio.

Individual, innovative solutions for every requirement
