24mm Stepper Motor

Voltage
3-24V
Load Current
300mA
Rated Speed
6-1875 rpm
Rated Torque Max. (gf.cm)
15000-20000gf.cm
Rated Torque Max. (mNm)
1470.99-1961.32mNm
Reduction Ratio
4-1296
Overall Length
49.8-69.8mm
24mm Stepper Motor
24mm Stepper Motor
24mm Stepper Motor

Gearbox Specifications:

Bearing Porous bearing Rolling bearing
Axial Endplay ≤0.2mm ≤0.2mm
Radial Loading on Output Shaft ≤120N ≤170N
Operating Temperature -30℃ ~ +100℃

Parameters:

Gearbox Stages 1 2 3 4
Reduction Ratio 4/6 16/24/36 64/96/144/216 256/384/576/864/1296
Max Rated Torque (gf.cm max) 20000 20000 20000 20000
Max Instant Torque (gf.cm max) 60000 60000 60000 60000
Gearbox Efficiency (%) 90 85 80 75
Length (mm) 19.0 25.0 32.0 39.0

Drawing:

24mm gearbox drawing

Motor Specifications:

Motors (Optional) Brushed DC motor, Brushless DC motor, Coreless motor, Stepper motor
Voltage (Optional) 3-24V
Input Speed ≤15000rpm
Current 300mA max

Performance Data:

Model Rated Speed Max Speed Max Rated Torque Max Instant Torque Reduction Ratio Length Overall Length
  rpm rpm gf.cm gf.cm   mm mm
ZWBMD024024-4 1150 1500 20000 60000 4 19.0 49.8
ZWBMD024024-6 767 1000 20000 60000 6 19.0 49.8
ZWBMD024024-16 288 375 20000 60000 16 25.0 55.8
ZWBMD024024-24 192 250 20000 60000 24 25.0 55.8
ZWBMD024024-36 128 167 20000 60000 36 25.0 55.8
ZWBMD024024-64 72 94 20000 60000 64 32.0 62.8
ZWBMD024024-96 48 63 20000 60000 96 32.0 62.8
ZWBMD024024-144 32 42 20000 60000 144 32.0 62.8
ZWBMD024024-216 21 38 20000 60000 216 32.0 62.8
ZWBMD024024-256 18 23 20000 60000 256 39.0 69.8
ZWBMD024024-384 12 16 20000 60000 384 39.0 69.8
ZWBMD024024-576 8 10 20000 60000 576 39.0 69.8
ZWBMD024024-864 5 7 20000 60000 864 39.0 69.8
ZWBMD024024-1296 4 6 20000 60000 1296 39.0 69.8

* The above specifications are subject to change without prior notice. They are for reference only and can be customized as required.
