Smart Drawer Lock Motor

Voltage
1.5V (customizable)
Load Current
160mA
Rated Torque Max. (gf.cm)
≥200gf.cm
No-load Speed
30±15%rpm
Reduction Ratio
171 (customizable)
Noise
≤50dB
Weight
3.6g
Smart Drawer Lock Motor
Smart Drawer Lock Motor
Smart Drawer Lock Motor

Feature:

  1. ZHAOWEI adopts 10MM-diameter planetary gearbox to improve the reliability of locking and unlocking.
  2. Low-noise. The gearbox for smart drawer lock controls the lock by pulling the lock cylinder, reducing the noise.
  3. It has high torque, light weight & compact size, high efficiency.

gear-motor-for-smart-drawer-lock
